Feature
- Solid core IEC current transformers for varied application
- compact size suitable for different sizes of conductors
- tropicalized rating for harsh environmental condition
- Well adpated CT as the accuracy class is better than rated accuracy
- multiple secondary terminal options for different mounting profile
Application
- Photovoltaic solar power,
- UPS,
- Battery,
- Datacenter
- DC switching power supply system
Specification
| Complementary | |
| current transformer type | Tropicalised for cable |
| current transformer ratio | 40/5 |
| [Ith] conventional free air thermal current | 2.4 kA |
| dynamic withstand current | 2.5 Ith |
| Maximum safety factor | 5 |
| [Ue] rated operational voltage | < 720 V AC 50/60 Hz |
| [Ui] rated insulation voltage | 3 kV |
| Mounting mode | By screws Clip-on |
| Mounting support | Mounting plate DIN rail |
| Width | 44 mm outside: |
| Height | 65 mm outside: |
| Depth | 30 mm frame: 37 mm total: |
| Diameter | 21 mm |
| Net weight | 0.19 kg |
| [Uimp] rated impulse withstand voltage | 3 kV |
| Electrical insulation class | Class B |
| Cable outer diameter | 21 mm |
| Sealing | With |
| Environment | |
| Standards | VDE 0414 IEC 61869-2 |
| Product certifications | CE |
| IP degree of protection | IP20 |
| Relative humidity | 0…95 % |
| Ambient air temperature for operation | -25…60 °C |
