Features
- Industrial-grade chip design, suitable for harsh working environments in industrial sites
- Fanless design, efficient physical heat dissipation, suitable for harsh industrial environments, durable
- Built-in watchdog technology, self-recovery from faults, ensuring stable operation of equipment
- Supports DC 9~36V wide voltage power supply, suitable for various on-site power supply methods
Specification
Parameter | Value |
Installation Method | 35mm Standard Rail Installation / Horizontal Installation |
Dimensions | 16210028.5mm |
Communication Interface | RS485 |
Ethernet | 10/100Mbit/s Adaptive Ethernet LAN |
I/O Configuration | 8-channel DI (Optocoupler Isolated), 8-channel DO (Relay Output) |
Serial Port Isolation | Optocoupler Isolation |
Serial Port Terminal Resistance | External 120Ω resistance can be added if needed |
Serial Port Parameters | Support baud rate from 1200 to 115200 |
Network Protocol | TCP/IP, Modbus TCP |
Photoelectric Isolation Voltage Input | 0-30V |
Relay Contact Load | (3A 250VAC, 3A 30VDC) |
Power Supply Voltage | 9-36VDC input, Nominal 24VDC |
Operating Current | Max.300mA@24V |
Operating Temperature | -40~85℃ |
Environmental Humidity | 5%-95% (No Condensation) |
IP Protection Level | IP30 |
Protection Level | Electrostatic/Surge/Pulse Group Level 3 |
