RS485 Remote IO

GCAN-8100 RS485 Remote IO

GCAN-8100 RS485 Remote IO can be used to connect Modbussystem anddistributedbus terminal module, and these terminal modules can be expanded in amodular way.A complete node consists of a bus coupler, 1-32 arbitrary number ofterminal modules and a terminalmodule
GCAN-8100ModbusBus Coupler usesstandard Modbusprotocol, a standard slavestation.The GCAN-8100 Bus Couplerhas two kinds of style, GCAN-8100-TCPsupports Modbus TCP communication, GCAN-8100-RTU supports Modbus RTUcommunication. Besides, the firmware can be upgraded by configuring the interface.
GCAN-8100 Bus Couplersupports automatic configuration,andyou do not need toset parameters on the PC. When GCAN-8100 bus coupler uses Modbus RTUcommunication, communication parameters can be configured by RS485 interface;When uses Modbus TCP communication, communication parameters can beconfigured by Ethernet interface

Contact us
Category:

Features

  • Support standard Modbus protocol, a standard Modus slave station
  • Support Modbus TCP, Modbus RTU communication (corresponding to two kinds of style)
  • RS485 interface adopts standard two-wires system
  • Serial interface baud rate supports 600bps~115200bps, configured by serial interface
  • The maximum number of bus terminalsmodule is 64
  • Configuration mode is automatic configuration, expandedfreely
  • Ethernet interface supports static or dynamic IP acquisition
  • Ethernet interface supports heartbeat and timeout disconnection
  • Ethernet work interfaces fixed, target IP and target interface can be set
  • Ethernet interface is compatible with the SOCKET working mode (TCP Server,TCP Client, UDP, etc.). The upper computer communication software complies with the standard SOCKET rules.
  • Supply power: 24V DC (-15%/+20%)
  • Input current, 70mA+ (total GC-bus current), maximum4500mA
  • Starting current: about 2.5 times continuous current
  • Power contacts: maximum 24V DC/maximum 10A
  • Electrical isolation: 1000 Vrms (power contact/bus coupled power voltage)
  • Working temperature: -40.00℃~ 85.00℃
  • Standard DIN rail, designed for industrial design
  • Dimensions：100mm(L) * 69mm(W) * 48mm(H)

Specification

Performance CANopen adapter (GCAN-IO-8000) Modbus adapter (GCAN-IO-8100)
Node number 1~127 1~247
Baud rate 10Kbps~1000Kbps 600bps~115200bps
Power input 24V DC (18~36V)
Insert I/O module number 32 pieces (at most 32*8 IO point)
Dimension 100mm*69mm*48mm
Working temperature, humdidness -40℃~+85℃， 0~90%RH， without condensation
IP grade IP20
Module feature
  • Standard CANopen slave station
  • Support 4 TPDO, 4 RPDO
  • Support 1 SDO, 1 emergency object, 1 node error control object
  • Start to perdefine connection, support parameters store
  • PDO mode supports synchronization, looping, event-driven, polling
  •  Configuration mode is automatic configuration
  • CAN interface: one open 4 terminal
  • Input current, 70mA+ ( total GC-bus current), maximum 2.5A
  • Starting current: about 2.5 times continuous current
  • Power contacts: maximum 24V DC/maximum 10A
  • Electrical isolation: 1500 Vrms
  • Support standard Modbus protocol, a standard Modus slave station
  • Support Modbus function code:01, 02, 03, 04, 05, 06, 15, 16
  • Support CRC validation
  • Support Modbus TCP, Modbus RTU communication (corresponding to two kinds of style)
  • RS485 interface adopts standard two-wires system
  • Serial interface baud rate supports 600bps~115200bps, configured by serial interface
  • The maximum number of bus terminals module is 64
  • Configuration mode is automatic configuration, expand freely
  • Ethernet interface supports static or dynamic IP acquisition
  • Ethernet interface supports heartbeat and timeout disconnection
  • Ethernetwork interface is fixed, target IP and target interface can be set
  • Automatic restoration of connection resources after the Ethernet interface is disconnected,and reliable establishment of TCP connections
  • Ethernet interface is compatible with the SOCKET working mode (TCP Server, TCP Client,UDP, etc.). The upper computer communication software complies with the standard SOCKET rules.
  • Input current, 70mA+ (total GC-bus current), maximum 4500mA
  • Starting current: about 2.5 times continuous current
  • Power contacts: maximum 24V DC/maximum 10A
  • Electrical isolation: 1000 Vrms (power contact/bus coupled powervoltage)
  • Standard DIN rail,designed for industrial design
