Automatic Temperature Controller

JTO011/JTS011 Automatic Temperature Controller thermostat with hand screw

The ZR011 Automatic Temperature Controller houses two separate thermostats, allowing the independent control of heating and cooling or other equipment. Both thermostats offer wide adjustment ranges and are color coded for easy function recognition.There are two types of this kind thermostat:JTO011 and JTS 011.
JTO011:Thermostat(normally closed);contact breaker for regulating heaters.
JTS011:Thermostat(normally closed),contact maker for regulating filter fans and heat exchangers or for switching signal device when the temperature limit has been exceeded.

Contact us
Category:

Features

  • Various installation methods of clips and screws for easy selection
  • Compared with the side mounted fan filter, the top exhaust fan has larger air volume and better heat dissipation effect
  • Various appearance forms, large choice

Specification

  • IP Rating: IP20
  • Certification: CE
  • Thermostatic Bimetal: Switch Temperature Difference,7K(+-4K Tolerance)
  • Casing: Plastic According to UL94 V-0,Light Grey
  • Installation: 35mm DIN Installation Guide
  • Contact Type: Snap-Action
  • Operating Temperature: -20-+80 Degree
  • Temperature: 0~+60ºC,Max. Switching Capacky
  • 250VAC,10A,120VAC,15A,30wdc at 24VDC to 72VDC
  • Service Life: >100000 Cycles
  • Transport Package: Standard Export Packing
  • Specification: 60*33*43
